Surface Material: Crafted from SUS304 stainless steel, with contact components employing SUS316L stainless steel and medical-grade silicone rubber, meeting GMP specifications.
Filling System: Utilizes a ceramic plunger pump for precise dosing in liquid formulations (screw pump for powder formulations). Dosing volume and speed are adjustable through the user interface, ensuring high accuracy, speed, and productivity.
Conveying System: Achieves sorting and transportation of rubber stoppers and aluminum caps through a vibrating tray, utilizing a clean SUS316L stainless steel tray with a polished surface, eliminating cleaning dead spots.
Control System: Incorporates internationally renowned electrical components for interference-free modular control. All synchronous actions are managed by servo motors, ensuring accuracy, reliability, and user-friendly operation.
Detection System: Equipped with a detection and warning system, ensuring functions like no-bottle-no-fill and automatic alarms. Electronic detection elements at each station, including filling, stoppering, capping, and crimping, enable continuous monitoring, preventing errors in the filling process.
Versatility: Offers a range of dosing volumes and methods, supporting the storage of various formula parameters.
Filling Method: Adopts a filling method where the filling needle rises with the liquid level, preventing drug splashing.
Cleanliness Options: Optional A-grade laminar flow hood available for high cleanliness production.
| Applicable Materials | Liquid， Powder，and gel |
| Applicable Specifications | 5-25ml(Requires change of plunger pump) |
| Filling Range | 0.1-25ml(Requires change of plunger pump) |
| Number of Filling Needles | 1~2 |
| Filling Accuracy | ≤±1-3% (According to material characteristics) |
| Production Capacity | Powder (Single Needle): 20-25/min Liquid (Double Needle): 30-40/min |
| Total Power | 3.5KW |
| Voltage | 380V 50Hz |
| Compressed Air | 0.6-0.7Mpa |
| Dimensions | L3300×W1900×H1800mm |
| Total Weight | 620KG |
30% advance payment upon contract signing, with the remaining 70% to be settled before shipment
The Vial Filling and Crimping Machine is a specialized equipment designed for the filling, stoppering, and crimping of vials, catering to pharmaceutical, medical, and cosmetic industries. It can be integrated with ultrasonic bottle washing, hot air circulation tunnel oven, bottle arranging machine, etc., enabling seamless operations including bottle arrangement, filling, stoppering, and crimping.
Hot Tags: Vial Filling And Crimping Machine, Vial Filling Machine, Vial Filling Line, Vial Filling And Capping Machine, Bottle Filling Equipment, Vial Crimping Machine, Auto Crimping Machine, Automatic Filling And Capping Machine, Pharmaceutical Filling Machine, Liquid Filling And Capping Machine, China, Customized, OEM, Low price, manufacturing company, manufacturers, factory, suppliers, quotation, for sale
Surface Material: Crafted from SUS304 stainless steel, with contact components employing SUS316L stainless steel and medical-grade silicone rubber, meeting GMP specifications.
Filling System: Utilizes a ceramic plunger pump for precise dosing in liquid formulations (screw pump for powder formulations). Dosing volume and speed are adjustable through the user interface, ensuring high accuracy, speed, and productivity.
Conveying System: Achieves sorting and transportation of rubber stoppers and aluminum caps through a vibrating tray, utilizing a clean SUS316L stainless steel tray with a polished surface, eliminating cleaning dead spots.
Control System: Incorporates internationally renowned electrical components for interference-free modular control. All synchronous actions are managed by servo motors, ensuring accuracy, reliability, and user-friendly operation.
Detection System: Equipped with a detection and warning system, ensuring functions like no-bottle-no-fill and automatic alarms. Electronic detection elements at each station, including filling, stoppering, capping, and crimping, enable continuous monitoring, preventing errors in the filling process.
Versatility: Offers a range of dosing volumes and methods, supporting the storage of various formula parameters.
Filling Method: Adopts a filling method where the filling needle rises with the liquid level, preventing drug splashing.
Cleanliness Options: Optional A-grade laminar flow hood available for high cleanliness production.
| Applicable Materials | Liquid， Powder，and gel |
| Applicable Specifications | 5-25ml(Requires change of plunger pump) |
| Filling Range | 0.1-25ml(Requires change of plunger pump) |
| Number of Filling Needles | 1~2 |
| Filling Accuracy | ≤±1-3% (According to material characteristics) |
| Production Capacity | Powder (Single Needle): 20-25/min Liquid (Double Needle): 30-40/min |
| Total Power | 3.5KW |
| Voltage | 380V 50Hz |
| Compressed Air | 0.6-0.7Mpa |
| Dimensions | L3300×W1900×H1800mm |
| Total Weight | 620KG |
30% advance payment upon contract signing, with the remaining 70% to be settled before shipment
The Vial Filling and Crimping Machine is a specialized equipment designed for the filling, stoppering, and crimping of vials, catering to pharmaceutical, medical, and cosmetic industries. It can be integrated with ultrasonic bottle washing, hot air circulation tunnel oven, bottle arranging machine, etc., enabling seamless operations including bottle arrangement, filling, stoppering, and crimping.
