1. Feed Water Preheating
The process begins with preheating feed water to remove non-condensables.
-
2. Evaporation and Superheating
The DTS heat exchanger uses plant steam (7-8 bar) to evaporate and superheat the water above its boiling point.
-
3. Separation Column
Expanding vapors enter a separation column where gravity separates heavier droplets, resulting in dry steam with a dryness fraction of ≥0.95.
-
4. Multi-Stage Monitoring
Continuous monitoring of temperature, pressure, conductivity, TOC, and endotoxins ensures the purity of the output before distribution.
-
5. Simultaneous Generation
The system can simultaneously produce WFI and pure steam in hybrid modes, optimizing space usage.
-
6. cGMP Manufacturing
The production adheres to current Good Manufacturing Practices (cGMP) at the Ningbo facility, ensuring qualified welding and material traceability.
-
7. Rigorous Validation
Every unit undergoes thorough validation, reinforcing Everheal's commitment as a leading Pure Steam Generator Manufacturer.
